Product form

The PRIME Series has always demonstrated outstanding performance and have become the epitome of technological excellence and quality through the... Read more

SKU: V28-PSUSEAPRIMEPX650

29 in stock

$441.95 $382.49 Excl. GST

Guaranteed secure & safe checkout.

Free shipping on selected products 🇦🇺

ABN: 24 621 799 273

↩️ 14-Day Hassle-Free Returns (in accordance with our Returns Policy and Australian Consumer Law)

Buy Now, Pay Later

Get your order today and pay later—no stress, no delays.
Simple, secure checkout with flexible payment options.
Read more

Description

The PRIME Series has always demonstrated outstanding performance and have become the epitome of technological excellence and quality through the years. This third generation of PRIME Series rolled out not only with a uniformed naming scheme but also with updated general design and connection cables. As each new model in these PRIME series have their distinctive set of features and specifications, prospective customers will find a streamlined buying guidance through understanding the One Seasonic process.

80 PLUS® Platinum certified
Micro Tolerance Load Regulation (0.5 %)
Cable-free Connection Design
Premium Hybrid Fan Control - Fanless until 40 % load
Multi-GPU setup
Gold plated connectors
12 years warranty

Specifications

Technical Specifications
80PLUS^®		Platinum
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		Intel ATX 12 V
Dimensions		140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information	Fan Size	135 mm
	Fan Control	Premium Hybrid Fan Control
	Fan Bearing	Fluid Dynamic Bearing
	Life Expectancy	50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Fully Modular
Cable Information	Cable type	Flat black cables
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF @ 25 °C, excl. fan	150,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Safety and Environmental	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		12 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 9 - 4.5 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	20 A	20 A	54 A	0.3 A	3 A
	Maximum Power	100 W		648 W	3.6 W	15 W
	Total continuous power	650 W

Cables

Cable type	Connector(s) per cable	Total Length (mm)	Number(s) of cable(s) included
MB (24/20 pins)	1	610	1
CPU (8/4 pins)	1	650	2
PCIe (8/6 pins)	2	750	0
PCIe (8/6 pins)	1	750	4
SATA	4	810	2
SATA	4	860	1
SATA	4	760	0
SATA	2	700	0
SATA	2	570	0
SATA	2	470	0
SATA	2	450	1
Molex	3	690	1
Molex	2	470	0
Molex to SATA 3.3 Adapter	2	300	1
Molex to FDD Adapter	1	101	0

Specifications are subject to change without prior notice.

Specifications

Weight: 200gr
Usage: Indoor & outdoor
